Velleman VM118 8-CHANNEL RF REMOTE CONTROL SET

See DIN-RAIL Attachment

Features

8-channel RF remote control set

latching or momentary mode for each output

8 addresses allow the use of multiple receivers

'All clear'- function

open field range up to 50m / 165ft.

optional extra transmitter type VM118R

suited for all kinds of applications such as light control, audio speaker selection, garden applications ...

Specifications

TRANSMITTER:

power supply: 3 AAA batteries (not incl.)

433MHz operation

8 digitally encoded channels

rubber keypad

LED function/mode indication

dimensions: 150x58x23mm

FCC approved ID code: NLO8058

RELAY RECEIVER CARD:

8 high-quality relay contacts, 5A/230Vac max.

relay outputs are transient suppressed using VDR's

LED confirmation on each relay contact

input power: 12Vac / 500mA

recommended housing: B8006

Extras

option

B8006 Din rail enclosure

Data Sheet
